| Frame: |
650B 120mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 Rear Axle , w/Replaceable Derailleur Hanger |
| Rear Shock: |
X-Fusion 02 Pro RL, Air, Ext Rebound, Lockout |
| Fork: |
RST First 27.5 Air, 120mm, Alloy Steerer, Magnesium Lowers, Hydraulic Damp, External rebound, Lockout, 1.5 Taper, 15Q |
| Headset: |
FSA Orbit 1.5E, Zero Stack, 1- 1/8″~1.5 |
| Rims: |
WTB STP-I23 TCS, Disc, Double Wall, 28H, Tubeless Ready |
| Hubs (F/R): |
Light Weight S/B Alloy Disc, 15mm, Straight Pull, Front,Light Weight S/B Alloy Disc, Cassette, 12 x 142mm, Straight Pull, Rear |
| Tires: |
Maxxis Ardent 27.5 x 2.25, 60 TPI Folding, Tubeless Ready |
| Spokes: |
14G Black w/Alloy Nipples, 28×28 |
| Derailleur, Front: |
n/a |
| Derailleur, Rear: |
Shimano SLX RD-M7000 |
| Shifters: |
Shimano SLX, SL-M7000, 11s, Trigger, Right Only |
| Chain: |
KMC X11-1 w/MissingLink |
| Crankset: |
Samox 2pc Forged w/Outboard Bearing, Narrow Wide 32T C/R |
| BB: |
Outboard Cartridge Bearing |
| Cassette: |
Sun Race 11-46T, 11-speed |
| Pedals: |
n/a |
| Seatpost: |
Alloy micro-adjust, 30.9x350mm |
| Saddle: |
WTB Volt Sport |
| Handlebar: |
Kore XCD 1 Riser, 760 x 18mm, 31.8mm |
| Stem: |
Kore XCD, Alloy 3D Forged, Threadless 4-bolt, 31.8mm |
| Grips: |
Q2 Lock-on |
| Brake Levers: |
Shimano M396 |
| Brakes: |
Shimano M396 Hydraulic Disc,160/160mm Rotors Wave 12 |
| Color: |
Matte Gray |
| Frame Size: |
S/15.5, M/17, L/19, XL/20.5 |
